In Stock

OPLLS0091C

Lens Part Number: OPLLS0091C
16in1 Street Light Lens (IP&IK)
Lens Material  : Polycarbonate
Lens Operating Temperature : -40°C to +120°C
Lens Dimensions (L x W x H) : 100mm X 60mm X 7.6mm
LED compatibility : Package 3030 / 3535 / 3737 / 2835
IP & IK Rating : IP-65 & IK-08
Application: Street Lighting
Gasket Material : Silicon
Distribution Type: Type II & Type I
Compare

Description

16in1 Cluster LED Lens for Street Light
This is 16in1 Street Light Lens suitable for 3030, 3535, 3737 & 2835 LED. Distribution Type can be achieved by adjusting Street Light mounting angle. We can provide IES File of Lens with respective LED on request. Datasheet & Drawing of the lens can be downloaded from below table. Please feel free to send any query about lens, we will get back to you with details accordingly.

LED Manufacturer

LED Model

FWTM Angle (°) Spread

FWTM Angle (°) Throw

Cd/lm

Efficiency (%)

Datasheet

SEOUL

Z5M2

100.35

152.75

0.64

89

Download

SAMSUNG

LH351B

101.05

152.1

0.58

90

Download

OSRAM

Oslon Square Gen3

102.74

157.98

0.48

90

Download

CREE

XP-E

149

105

0.51

89

Download

CREE

XP-E2

153

108

0.5

89

Download

CREE

XP-G2

157

109

0.53

89

Download

CREE

XT-E

162

115

0.52

89

Download

EDISON

3535 FX

154

104

0.49

88

Download

LG INNOTEK

H35C1

159

114

0.52

89

Download

SAMSUNG

LH351B

154

106

0.52

89

Download

CREE

XP-G3

162

118

0.5

88

Download
